Layer Microphone with Knob and Radio Buttons Single-Din car radio player with 2 video output, 2 AUX inputs, 4 RCA outputs, Sunplus-8202 with BT, USB, SD card
Item #: DP9032
sing-din car dvd receiver supplier and manufacturer
SPECIFICATIONS
| CPU | SPHE8202R-D Sunplus |
| MCU | SWT8M188C |
| RAM | DDR64M |
| Flash | SPI FLASH 8M |
| Amplifier IC | TDA 7388 |
| Radio IC | SI4702/SI4730 |
| Bluetooth IC | SWT8M188C bluebooth4.2 |
| USB interface | USB1; |
| Multimedia Parameters | |
| Music format | MP3、WMA、AAC、RM、LFAC etc |
| Radio Parameters | |
| frequency range | FM：76.0MHz-108.0MHz, AM: 522KHz-1710KHz |
| Radio storage station | FM/AM/RDS |
| Radio area | Global |
| Working voltage and memory current parameters | |
| working voltage | 9V～16V |
| working temperature | 一20℃一60℃ |
| Memory current | < 6MA |
| Power amplifier parameters | |
| Test voltage | 14.4V |
| Maximum output power | 4*25W |
FEATURES
Single-DIN Car DVD Player
4 RCA outputs
2 AUX inputs
2 Video output
MIC connector
Bluetooth
USB and SD Player
WARRANTY
Warranty: 18 Months Manufacturer warranty
We provide a warranty service of 18 months after the arrival of the goods and provide free accessories and maintenance instructions. If you have any questions within 18 hours from 6：00 am to 12：00 pm every day, you can contact our after-sales team online to get timely support.
